CYT-P32DC mobile hydraulic hose crimper is suitable for hydraulic repair mobile service. The machine is battery powered with 12V or 24V. It can crimp 1/4” to 2” 4 layers of hose. The compact design allows this crimper to be mounted in a service van.
| Crimping Range | 10mm to 87mm |
|---|---|
| Max. Hydraulic Hose | 2" 4SP |
| Max. Opening | +/-33mm |
| System Pressure | 31.5Mpa |
| Dies Quantity | 13sets |
| Max. Crimping Force | 2000KN |
| Motor Power | 4kw |
| Control | Automatic |
| Slide Rails | Has |
| Dies Rack | Optional |
| Dies Quick Change Dies Tool | Optional |
| Weight | 270KGS |
| Dimension | 600*1100*700mm |
This hydraulic hose crimping machine inculdes 13sets of dies. Besides, the quick change dies tool and dies rack can be optional.
It is with tray and can put bettery inside. In addition, it is also with slide rails and save space.
